Set Point Ranges
3–150 psi (0.2-10.3 bar)
Repeatability
± 2% FS
Maximum Overpressure
350 psi (24 bar)
Mechanical Capability
Medium pressure switch
Mechanical Life
1,000,000 Cycles
Temperature Range
-20–180°F (-29-82°C)
Housing Material
Brass, Optional: Stainless Steel—may extend delivery time
Diaphragm
Nitrile (other options available on request)
Pressure Port
¼" NPT Male
Environmental Protection
IP 65
Electrical Connection
Din 43650 A
Weight
0.26 lbs (0.12 kg)
Switch Type
SPDT Snap Action
Current Rating
5 A 12/24 VDC – 125 VAC
3 A 250 VAC
Optional: 10 A or Gold Contacts—may extend delivery time
