VEP 490 SERIES

VEP 490 SERIES Specifications

• Mechanical

  Standard Tolerance
  ±10%

  Switch Type
  SPDT (single pole / double throw)

  Switching Medium
  Air or compatible fluids

  Mechanical Capability
  Pressure switch

  Mechanical Life
  100,000 cycles

  Set-Point Ranges
  3.0 to 3000 PSI

  Proof Pressure
  4500 PSI

  Hysteresis
  10% to 40% of set point

  Operating Temp.
  -65°F to 180°F

  Electrical Connections
  Wire leads or Mate n lok 1-480701

  Weight
  Less than 2 ounces

• Physical

  Case Material
  2024T351 Aluminum Gold Anodized or
  303 Stainless Steel

  Seal
  Varies by option - See Detailed Specs sheet

  Piston
  303 Stainless Steel

  Pressure Port
  Many standard ports - See Detailed Specs sheet

• Electrical

  Current Rating
  Resistive 5 AMP

  Operating Voltage
  30VDC
