VEP - Value Engineered Products Pressure Switches

Aerospace Pressure Switches • Vacuum Switches • Differential Switches

  1. 490 SERIES

    • Pressure switch
    • Field adjustable pressure ranges up to 3000 PSI
    • Lightweight, aluminum body, pressure switch
    • Dual spring design for accuracy & stability
    • Piston design to allow high proof pressures
    • Suitable for altitude ranges from -1000 to 50,000 ft
    • Designed to meet FAA's 15 min flame test requirements
    View Details
  2. 654 SERIES

    • Ultra-low Pressure / Vacuum / Differential
    • Low ranges down to 0.01 PSI
    • Lightweight aluminum construction
    • Design suitable for both wet and dry media
    • Fully enclosed design for harsh environments
    • SPDT & DPDT electrical switch options available
    View Details
  3. 658 SERIES

    • Dual differential pressure switch
    • Switch Ranges from 40 to 500 PSIG
    • Factory set, tamper proof
    • Lightweight aluminum construction
    • Dual spring design for accuracy & stability
    • One piece fully supported diaphragm to achieve both low set-point and high proof pressure
    • Fully enclosed design for harsh environments
    View Details
  4. 670 SERIES

    • Pressure / Vacuum
    • Switch Range from 1.5 to 400 PSIG
    • Factory set, tamper proof
    • Lightweight aluminum or stainless steel housing available
    • Dual spring design for accuracy & stability
    • One piece fully supported diaphragm to achieve both low set-point & high proof pressure
    • Stainless steel model designed to meet FAA's 15 min flame test requirements
    View Details
  5. 680 SERIES

    • Pressure / Vacuum
    • Switch Range from 1.5 to 400 PSIG
    • Lightweight aluminum construction
    • Fully integrated electrical connector
    • Double pole, double throw switching option
    • Excellent operating temperature range from -65 to +400F
    • Wide selection of pressure ports & configurations for easy installation
    View Details
