Standard Tolerance
±10%
Switch Type
SPDT (single pole / double throw)
Switching Medium
Air or compatible fluids
Mechanical Capability
Pressure switch, vacuum switch
Mechanical Life
100,000 cycles
Set-Point Ranges
1.5 to 400 PSI (0.1–27.6 bar)
Proof Pressure
1000 PSI (69 bar)
Hysteresis
10% to 40% of set point
Operating Temp.
-65°F to 400°F (-54°–204°C)
Case Material
Aluminum, Gold Anodized
Seal
Varies by option - See Detailed Specs sheet
Diaphragm
Stainless Steel
Pressure Port
Many standard ports - See Detailed Specs sheet
Electrical Connections
Many standard electrical connections - See Detailed Specs sheet
Weight
Less than 2.5 ounces
Current Rating
Resistive 5 AMP
Operating Voltage
30VDC
