VEP 680 SERIES

VEP 680 SERIES Specifications

• Mechanical

  Standard Tolerance
  ±10%

  Switch Type
  SPDT (single pole / double throw) or DPDT (double pole / double throw)

  Switching Medium
  Air or compatible fluids

  Mechanical Capability
  Pressure switch, vacuum switch

  Mechanical Life
  100,000 cycles

  Set-Point Ranges
  1.5 to 400 PSI

  Proof Pressure
  1000 PSI

  Hysteresis
  10% to 40% of set point

  Operating Temp.
  -65°F to 400°F

• Physical

  Case Material
  2024T351 Aluminum, Gold Anodized or 303 Stainless Steel

  Seal
  Buna n, Neoprene, Silicone or Stainless Steel

  Diaphragm
  302 Stainless Steel

  Pressure Port
  Many standard ports - See Detailed Specs sheet

  Electrical Connections
  Many standard electrical connections - See Detailed Specs sheet

  Weight
  Less than 6 ounces



• Electrical

  Current Rating
  Resistive 5 AMP

  Operating Voltage
  30VDC
