Military Approved DesignFlex PSF100A Switch Series - Patented, Shock and Vibration Resistance

Shock and Vibration Resistant, the DesignFlex PSF100A Pressure Switch Series is Approved for Military Applications


Press Release   7/20/2011
Traverse City, Michigan

display of military approved MIL-STD-167-1 & MIL-STD-901-D designflex PSF100A pressure switch from DesignFlex by World Magnetics.

World Magnetics is pleased to announce the approval of its DesignFlex PSF100A Pressure, Differential Pressure, and Vacuum switch to the latest Military shock and vibration standards (MIL-STD-167-1 & MIL-STD-901-D).

The Patented double-contact, double-diaphragm configuration makes this product unique in the pressure switch industry and offers a configuration which virtually eliminates false actuation.

Available with a wide range of set points from 0.5-50” H2O and excellent switch point tolerances, this switch has been the choice of military contractors since 1965. Due to its compact, lightweight design and ability to switch up to 30VDC at 40mA max, this switch is the perfect product to interface into PC’s, PLC’s or other logic circuits.

The PSF100A has a recognized Cage Code (0C579) and has successfully be used on military and commercial applications alike. From measuring airspeed of aircraft to sip & puff controllers of wheelchairs the PSF100A is the perfect choice for cost effective pressure detection in harsh environments.

World Magnetics | DesignFlex switch products are engineered and crafted at our global manufacturing facility and world headquarters located in Traverse City, Michigan, USA. Our passionate customer focus and complete end-to-end manufacturing
capabilities provide many customer benefits, including simplified custom engineering; quick service; and high-quality, durable product solutions.


display of military approved MIL-STD-167-1 & MIL-STD-901-D designflex PSF100A pressure switch schematic from DesignFlex by World Magnetics

For information on this and other switches in the DesignFlex
product range, please visit or contact:

World Magnetics | DesignFlex
Web: www.worldmagnetics.com/our-brands/designflex-switches.html
E-mail: mpaul@worldmagnetics.com
Tel : 231 946 3800
Fax : 231 946 0274
Toll Free: 800 643 3384

DesignFlex Switches Press Release - 07/20/2011
Written By:  Martin Paul
